Intel® Server Chassis SC5400 Installation
Intel® Server Chassis SC5400 Installation
NOTE
This section only applies to drive cage upgrade kit installations in the Intel® Server
Chassis SC5400, SC5400 BRP, or SC5400 LX.
Remove the Access Cover
When your chassis is upright (in a tower/pedestal position), and you are facing the front of it, the access
cover is on the left side.
If your chassis is in a rack-mount configuration, the left side is already on the top.
To remove the access cover:
1. Observe all safety and ESD precautions listed at the beginning of this document.
2. Power the system off and disconnect the power cable(s).
3. Remove the access cover screw, if necessary (letter “A”).
4. If the bezel is locked, unlock it.
5. Press the latch (letter “B”)
6. Slide the cover towards the rear of the chassis.
7. Lift the cover outward to remove it.
Figure 1. Removing Access Cover
