Intel BLKD915GAGL - D915 GAG Board Components Shown in Figure 2

Product Description
17
Table 5. D915GAG Board Components Shown in Figure 2
Item/callout
from Figure 2 Description
A
ATAPI CD-ROM connector (optional)
B
PCI Express x1 bus add-in card connectors
C
Realtek ALC860 audio codec
D
S/PDIF connector (optional)
E
Front panel audio connector
F
PCI Conventional bus add-in card connectors
G
Ethernet PLC device (optional)
H
PCI Express x16 bus add-in card connector
I
Rear chassis fan connector
J
Back panel connectors
K
Alternate power connector
L
+12V power connector (ATX12V)
M
LGA775 processor socket
N
Hardware monitoring and fan control ASIC
O
Processor fan connector
P
Intel 82915G GMCH
Q
DIMM Channel A sockets
R
Serial port B connector (optional)
S
DIMM Channel B sockets
T
SCSI LED connector (optional)
U
I/O controller
V
Power connector
W
Diskette drive connector
X
Parallel ATE IDE connector
Y
Battery
Z
Chassis intrusion connector
AA
BIOS Setup configuration jumper block
BB
4 Mbit Firmware Hub (FWH)
CC
Front chassis fan connector
DD
Serial ATA connectors
EE
Auxiliary front panel power LED connector
FF
Front panel connector
GG
Front panel USB connector
HH
Intel 82801FB I/O Controller Hub (ICH6)
II
Front panel IEEE-1394a connectors (optional)
JJ
IEEE-1394a controller (optional)
KK
Speaker
