Product Description
19
1.4 Online Support
To find information about… Visit this World Wide Web site:
Intel Desktop Boards D915GAV and
D915GAG under “Desktop Board
Products” or “Desktop Board Support”
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
Available configurations for the Desktop
Board D915GAV
http://developer.intel.com/design/motherbd/av/av_available.htm
Available configurations for the Desktop
Board D915GAG
http://developer.intel.com/design/motherbd/ag/ag_available.htm
Processor data sheets http://www.intel.com/design/litcentr
ICH6 addressing http://developer.intel.com/design/chipsets/datashts
Custom splash screens http://intel.com/design/motherbd/gen_indx.htm
Audio software and utilities http://www.intel.com/design/motherbd
LAN software and drivers http://www.intel.com/design/motherbd
1.5 Processor
The boards are designed to support Intel Pentium 4 processors in an LGA775 processor socket with
an 800 or 533 MHz system bus. See the Intel web site listed below for the most up-to-date list of
supported processors.
For information about… Refer to:
Supported processors for the D915GAV board http://www.intel.com/design/motherbd/av/av_proc.htm
Supported processors for the D915GAG board http://www.intel.com/design/motherbd/ag/ag_proc.htm
CAUTION
Use only the processors listed on web site above. Use of unsupported processors can damage the
board, the processor, and the power supply.
#
INTEGRATOR’S NOTE
• Use only ATX12V-compliant power supplies.
• Refer to Table 6 on page 20 for a list of supported system bus frequency and memory speed
combinations.
For information about Refer to
Power supply connectors Section 2.8.2.2, page 72
