Intel BLKD915GAGL - Component-Side Connectors Shown in Figure 20

Technical Reference
69
Table 21 lists the component-side connectors identified in Figure 20.
Table 21. Component-side Connectors Shown in Figure 20
Item/callout
from Figure 20 Description
A
S/PDIF connector (optional)
B
Front panel audio connector
C
PCI Conventional bus add-in card connector 2
D
Front panel IEEE-1394a connector (optional)
E
PCI Conventional bus add-in card connector 1
F
PCI Express x16 bus add-in card connector
G
Rear chassis fan connector
H
Alternate power connector
I
+12V power connector (ATX12V)
J
Processor fan connector
K
Serial port B (optional)
L
SCSI LED (optional)
M
Power connector
N
Diskette drive connector
O
Parallel ATA IDE connector
P
Chassis intrusion connector
Q
Front chassis fan connector
R
Serial ATA connector 1
S
Serial ATA connector 3
T
Serial ATA connector 2
U
Serial ATA connector 0
V
Auxiliary front panel power LED connector
W
Front panel connector
X
Front panel USB connector
Y
Front panel USB connector
Z
Front panel IEEE-1394a connector (optional)
AA
PCI Express x1 bus add-in card connector 1
BB
ATAPI CD-ROM connector (optional)
