Intel Desktop Board D915GAV/D915GAG Technical Product Specification
64
2.8.1 Back Panel Connectors
Figure 18 shows the location of the back panel connectors. The back panel connectors are
color-coded. The figure legend (Table 19) lists the colors used (when applicable).
OM16670
A
B
K
FC
L
I
JGD E H
Figure 18. Back Panel Connectors
Table 19 lists the back panel connectors identified in Figure 18.

NOTE
The back panel audio line out connector is designed to power headphones or amplified speakers
only. Poor audio quality occurs if passive (non-amplified) speakers are connected to this output.
