Intel BOXDH57JG

Desktop Board Features
13
Table 2. Intel Desktop Board DH57JG Components
Label Description
A Back panel connectors
B Front panel USB 2.0 header
C Front panel header
D Chassis intrusion header
E Alternate front panel power LED header
F BIOS configuration jumper block
G Serial ATA connectors (4)
H Front panel USB 2.0 header
I Front panel USB 2.0 header
J Chassis fan header
K Main power connector (2 x 12 pin)
L Processor fan header
M Standby power indicator LED
N Channel A DIMM 0 socket
O Channel B DIMM 0 socket
P Speaker
Q Processor socket
R Serial port header
S PCI Express 2.0 x16 add-in card connector
T S/PDIF header
U Battery
V Front panel audio header
W 12 V processor core voltage connector (2 x 2 pin)
