Graphics Subsystem
The board supports system graphics through either Intel HD Graphics or a PCI Express
2.0 x16 add-in graphics card.
Integrated Graphics
The board supports integrated graphics through the Intel
®
Flexible Display Interface
(FDI) for processors with Intel HD Graphics.
Intel
®
HD Graphics
The Intel HD Graphics controller features the following:
• 3D Features
⎯ DirectX10* and OpenGL* 2.1 compliant
⎯ Shader Model 4.0
• Video
⎯ Hi-Definition content at up to 1080p resolution
⎯ Hardware accelerated MPEG-2, VC-1/WMV, and H.264/AVC High-Definition
video formats
⎯ Intel
®
Clear Video HD Technology with advanced video processing
• Dynamic Video Memory Technology (DVMT) 5.0 support including support of up to
1.7 GB Video Memory with a 4 GB and above system memory configuration
High-Definition Multimedia Interface* (HDMI*)
The HDMI port supports standard, enhanced, or high-definition video, plus multi-
channel digital audio on a single cable. It is compatible with all ATSC and DVB HDTV
standards and supports eight full range channels at 24-bit/96-kHz audio of lossless
audio formats such Dolby* TrueHD or DTS* HD Master Audio. The maximum
supported resolution is 1920 x 1200 at 60 Hz refresh (WUXGA). The HDMI port is
compliant with the HDMI 1.3 specification.
The HDMI port is enabled for the POST whenever a monitor is attached, regardless of
the DVI-I connector status.
Depending on the type of add-in card installed in the PCI Express x16 connector, the
HDMI port will behave as described in Table 3.
Table 3.
HDMI Port Status Conditions
PCI Express x16 Connector Status HDMI Port Status
No add-in card installed Enabled
Non-video PCI Express x1, x4, or x8 add-in card installed Enabled
PCI Express x4, x8, or x16 graphics add-in card installed Disabled

Intel BOXDH57JG Specifications

General

ECC	No
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	8 GB
Product family	Desktop board
Product series	Legacy Intel desktop board
Processor socket	LGA 1156 (Socket H)
Product codename	Jet Geyser
Processor manufacturer	Intel
USB 2.0 connectors	12
S/PDIF out connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Audio chip	Realtek ALC889
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H57 Express
Audio output channels	7.1+2 channels
Motherboard chipset ID	42700
Motherboard form factor	mini ITX
LAN controller	Intel® 82578DC
Networking features	10/100/1000 Mbit
Graphics output	HDMI, DVI-I
Motherboard ARK ID	42485
Discrete graphics card model	PCIe x16
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Status	Discontinued
Form factor	Mini-ITX
Last change	63903513
Launch date	Q1'10
Sustainability certificates	ENERGY STAR
Supported RAID configuration	0, 1, 5, 10 & Matrix
Harmonized System (HS) code	8473301180
