1 Desktop Board Features
This chapter briefly describes the features of Intel
®
Desktop Board DH57JG. Table 1
summarizes the major features of the Desktop Board.
Table 1. Feature Summary
Form Factor
Mini-ITX (170.18 millimeters [6.7 inches] x 170.18 millimeters
[6.7 inches])
Processor
• Intel
®
Core™ i5-600 series, Intel
®
Core™ i3, and Intel
®
Pentium
processors in an LGA1156 socket:
― Integrated graphics processing (processors with Intel
®
HD
Graphics)
― External graphics interface controller
― Integrated memory controller
Chipset Intel
®
H57 Express Chipset consisting of the Intel
®
H57 Express
Platform Controller Hub (PCH)
Memory
• Two 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM)
sockets
• Dual Channel DDR3 1333 MHz and DDR3 1066 MHz support
• Support for 1 Gb and 2 Gb memory technology
• Support for up to 8 GB of system memory with two DIMMs using
2 Gb memory technology
• Support for non-ECC memory
Graphics
• Integrated graphics support for processors with Intel HD Graphics:
― High-Definition Multi-media Interface* (HDMI*)
― DVI-I
• Discrete graphics support for PCI Express* 2.0 x16 add-in graphics
card
Audio
• 10-channel (7.1+2) Intel
®
High Definition Audio (Intel
®
HD Audio)
using a Realtek* ALC889 audio codec
• 8-channel (7.1) Intel HD Audio via the HDMI port
Expansion
Capabilities
One PCI Express 2.0 x16 add-in card connector
continued

Intel BOXDH57JG Specifications

General

ECC	No
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	8 GB
Product family	Desktop board
Product series	Legacy Intel desktop board
Processor socket	LGA 1156 (Socket H)
Product codename	Jet Geyser
Processor manufacturer	Intel
USB 2.0 connectors	12
S/PDIF out connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Audio chip	Realtek ALC889
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H57 Express
Audio output channels	7.1+2 channels
Motherboard chipset ID	42700
Motherboard form factor	mini ITX
LAN controller	Intel® 82578DC
Networking features	10/100/1000 Mbit
Graphics output	HDMI, DVI-I
Motherboard ARK ID	42485
Discrete graphics card model	PCIe x16
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Status	Discontinued
Form factor	Mini-ITX
Last change	63903513
Launch date	Q1'10
Sustainability certificates	ENERGY STAR
Supported RAID configuration	0, 1, 5, 10 & Matrix
Harmonized System (HS) code	8473301180
