Intel BOXDH57JG User Manual

Intel Desktop Board DH57JG Product Guide
14
Online Support
For more information on Intel Desktop Board DH57JG consult the following online
resources:
• Intel Desktop Board DH57JG http://www.intel.com/products/motherboard/DH57JG/
index.htm
• Desktop Board Support http://www.intel.com/support/motherboards/desktop/
DH57JG
• Available configurations for Intel
Desktop Board DH57JG
http://www.intel.com/products/motherboard/DH57JG/
index.htm
• Supported processors http://processormatch.intel.com
• Chipset information http://www.intel.com/products/desktop/chipsets/inde
x.htm
• BIOS and driver updates http://downloadcenter.intel.com/
• Integration information http://www.intel.com/support/go/buildit
• Mini-ITX chassis compatibility http://www.intel.com/go/miniitx
Processor
CAUTION
Failure to use an appropriate power supply and/or not connecting the 12 V (2 x 2 pin)
power connector to the Desktop Board may result in damage to the board, or the
system may not function properly.
Intel Desktop Board DH57JG supports the Intel Core i5-600 series, Intel Core i3, and
Intel Pentium processors in an LGA1156 socket. Processors are not included with the
Desktop Board and must be purchased separately. The processor connects to the
Desktop Board through the LGA1156 socket.
For information on supported processors for Intel Desktop Board DH57JG, go to
http://processormatch.intel.com
.

Intel BOXDH57JG Specifications

General

ECC	No
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	8 GB
Product family	Desktop board
Product series	Legacy Intel desktop board
Processor socket	LGA 1156 (Socket H)
Product codename	Jet Geyser
Processor manufacturer	Intel
USB 2.0 connectors	12
S/PDIF out connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Audio chip	Realtek ALC889
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H57 Express
Audio output channels	7.1+2 channels
Motherboard chipset ID	42700
Motherboard form factor	mini ITX
LAN controller	Intel® 82578DC
Networking features	10/100/1000 Mbit
Graphics output	HDMI, DVI-I
Motherboard ARK ID	42485
Discrete graphics card model	PCIe x16
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Status	Discontinued
Form factor	Mini-ITX
Last change	63903513
Launch date	Q1'10
Sustainability certificates	ENERGY STAR
Supported RAID configuration	0, 1, 5, 10 & Matrix
Harmonized System (HS) code	8473301180
