Intel Desktop Board DH57JG Product Guide
70
Lead-free 2LI/Pb-free 2LI Board
The electronics industry is transitioning to European Union (EU) Restriction of
Hazardous Substances (RoHS)-compliant products. The RoHS legislation restricts the
use of six materials. One of these restricted materials is lead. Lead is the most
common and problematic of the RoHS restricted materials.
There are exemptions in RoHS that allow the use of lead in some very limited locations
in electronic products. Maximum lead concentration values have been established for
RoHS-compliant electronic products that allow up to 1000 ppm of lead.
Lead-free/Pb-free is a nickname that is often used (or misused) for RoHS-compliant
products. In this case, the term "Lead-free/Pb-free" means that lead has been
removed where required by the RoHS legislation but still may exist as an impurity
below 1000 ppm.
The term "Lead-free 2LI/Pb-free 2LI" means lead-free second level interconnect (2LI).
The balls, leads, or pads used to connect the component to a printed circuit board are
lead-free, but the first level interconnect (FLI) is not lead-free. The use of lead in the
FLI is acceptable because of the RoHS "flip chip" or "die bump" interconnect
exemption.
Intel Desktop Board DH57JG is a lead-free second level interconnect product.
Table 20 shows the lead-free second level interconnect
marks as they appear on the
board and a
ccompanying collateral. These marks are based on JEDEC standard
J-STD-609, “Marking and Labeling of Components, PCBs and PCBAs to Identify Lead,
Lead Free and Other Attributes.”
For more information concerning Intel’s lead-free initiatives, refer to:
http://www.intel.com/technology/silicon/leadfree.htm
.

Intel BOXDH57JG Specifications

General

ECC	No
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	8 GB
Product family	Desktop board
Product series	Legacy Intel desktop board
Processor socket	LGA 1156 (Socket H)
Product codename	Jet Geyser
Processor manufacturer	Intel
USB 2.0 connectors	12
S/PDIF out connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Audio chip	Realtek ALC889
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H57 Express
Audio output channels	7.1+2 channels
Motherboard chipset ID	42700
Motherboard form factor	mini ITX
LAN controller	Intel® 82578DC
Networking features	10/100/1000 Mbit
Graphics output	HDMI, DVI-I
Motherboard ARK ID	42485
Discrete graphics card model	PCIe x16
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Status	Discontinued
Form factor	Mini-ITX
Last change	63903513
Launch date	Q1'10
Sustainability certificates	ENERGY STAR
Supported RAID configuration	0, 1, 5, 10 & Matrix
Harmonized System (HS) code	8473301180
