Intel Desktop Board D525MW and Intel Desktop Board D525MWV Technical Product
Specification
12
Table 1. Feature Summary (continued)
BIOS
• Intel
®
BIOS (resident in the SPI Flash device)
• Support for Advanced Configuration and Power Interface (ACPI), Plug and
Play, and SMBIOS
Instantly Available
PC Technology
• Support for PCI* Local Bus Specification Revision 2.3
• Suspend to RAM support
• Wake on PCI, PCI Express*, PS/2, serial, front panel, USB ports, and LAN
Expansion
Capabilities
• One PCI Conventional bus connector (with riser card support for up to two PCI
cards)
• PCI Express x1 Mini Card connector
Hardware Monitor
Subsystem
• Hardware monitoring through the Windbond I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• One fan header
• One fan sense input used to monitor fan activity
• Fan speed control
