Intel Desktop Board D525MW and Intel Desktop Board D525MWV Technical Product
Specification
18
1.4 System Memory
The board has two 204-pin DDR3 SO-DIMM sockets and supports the following
memory features:
• DDR3 SDRAM SO-DIMMs with gold-plated contacts
• Unbuffered, single-sided or double-sided DIMMs
• 4 GB maximum total system memory
• Minimum total system memory: 256 MB
• Non-ECC DIMMs
• Serial Presence Detect
• DDR3 800 MHz, DDR3 1066 MHz, and DDR3 1333 MHz SO-DIMMs
(DDR3 1066 MHz and DDR3 1333 MHz memory will run at 800 MHz)
NOTE
Due to passively-cooled thermal constraints, system memory must have an operating
temperature rating of 85
o
C.
The board is designed to be passively cooled in a properly ventilated chassis. Chassis
venting locations are recommended above the system memory area for maximum heat
dissipation effectiveness.
NOTE
To be fully compliant with all applicable DDR3 SDRAM memory specifications, the
board should be populated with DIMMs that support the Serial Presence Detect (SPD)
data structure. This allows the BIOS to read the SPD data and program the chipset to
accurately configure memory settings for optimum performance. If non-SPD memory
is installed, performance and reliability may be impacted or the DIMMs may not
function under the determined frequency.
Table 3 lists the supported SO-DIMM configurations.
Table 3. Supported Memory Configurations
DIMM
Capacity
Configuration
SDRAM
Density
SDRAM Organization
Front-side/Back-side
Number of
SDRAM Devices
1024 MB DS 1 Gbit 64 M x16/64 M x16 8
1024 MB SS 1 Gbit 128 M x8/empty 8
2048 MB DS 2 Gbit 128 M x16/128 M x16 8
2048 MB SS 2 Gbit 256 M x8/empty 8
Note: In the second column, “DS” refers to double-sided memory modules (containing two rows of SDRAM)
and “SS” refers to single-sided memory modules (containing one row of SDRAM).
