Intel Desktop Board D525MW and Intel Desktop Board D525MWV Technical Product
Specification
20
1.5.1.4 Configuration Modes
For monitors attached to the VGA port, video modes supported by this board are based
on the Extended Display Identification Data (EDID) protocol.
Video mode configuration for LVDS displays (D525MWV only) is supported as follows:
• Automatic panel identification via Extended Display Identification Data (EDID) for
LVDS panels supporting EDID protocol.
• Manual LVDS panel configuration through the BIOS setup page. This feature allows
the manual entry of critical panel settings (equivalent to the 18-byte Detailed
Timings Descriptor structure defined by the VESA EDID specification) for non-EDID
panel support.
In addition, BIOS setup provides the following configuration parameters for LVDS
displays (D525MWV only):
• Screen Brightness: allows the end-user to set screen brightness for the display.
• Maintain Aspect Ratio: allows the end-user to select whether the native aspect ratio
is to be preserved during POST and before the video driver is loaded.
• LVDS Configuration Changes: allows the system integrator to “lock” critical settings
of the LVDS configuration to avoid end-users potentially rendering the display
unusable (refer to Note 1).
• Inverter Frequency and Polarity: allows the system integrator to set the operating
frequency and polarity of the panel inverter board.
• Minimum Inverter Current Limit (%): allows the system integrator to set minimum
PWM%, as appropriate, according to the power requirements of the LVDS display
and the selected inverter board.
NOTE
Support for LVDS (D525MWV only) configuration complies with the following:
1. “Unlocking” of critical settings of the LVDS configuration is supported via Intel
®
Integrator Toolkit’s command-line tool.
2. Critical settings of the LVDS configuration are not exposed through Intel Integrator
Toolkit or Intel
®
Integrator Assistant GUIs.
3. Critical settings of the LVDS configuration will not be overwritten by loading BIOS
setup defaults.
4. Critical settings of the LVDS configuration will be preserved across BIOS updates.

Intel D525MW Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Single-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	4 GB
Supported memory clock speeds	800, 1066 MHz
Product family	Desktop board
Product series	Intel® Desktop Boards with Intel Atom® Processors
Processor socket	-
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
Parallel ports quantity	1
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® NM10 Express
Audio output channels	5.1 channels
Motherboard chipset ID	47610
Motherboard form factor	mini ITX
Motherboard chipset family	Intel
Compatible operating systems	Windows XP, Vista, 7
Parallel processing technology support	Not supported
Networking features	10/100/1000
Audio channels	6
Graphics output	VGA
Motherboard ARK ID	48952
Discrete graphics card model	None
Commodity Classification Automated Tracking System (CCATS)	NA
Status	Discontinued
Form factor	Mini-ITX
Last change	63903513
Launch date	Q4'10
USB ports quantity	7
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Harmonized System (HS) code	8471500150

Weight and Dimensions

Width	- mm
