Intel Desktop Board D525MW and Intel Desktop Board D525MWV Technical Product
Specification
32
1.11.2 Hardware Support
The board provides several power management hardware features, including:
• Power connector
• Fan header
• LAN wake capabilities
• Instantly Available PC technology
• Wake from USB
• Wake from PS/2 devices
• Power Management Event signal (PME#) wake-up support
• WAKE# signal wake-up support
• +5V Standby Power Indicator LED
LAN wake capabilities and Instantly Available PC technology require power from the
+5 V standby line.
NOTE
The use of Wake from USB technologies from an ACPI state requires an operating
system that provides full ACPI support.
1.11.2.1 Fan Header
The function/operation of the fan header is as follows:
• The fan is on when the board is in the S0 state.
• The fan is off when the board is off or in the S3, S4, or S5 state.
• The chassis fan header supports closed-loop fan control that can adjust the fan
speed and is wired to a fan tachometer input.
• The fan header supports +12 V, 3-wire fans at 1 A maximum.
For information about
Refer to
The locations of the fan header and thermal sensors Figure 5, page 28
The signal names of the chassis fan header Table 16, page 43
1.11.2.2 LAN Wake Capabilities
LAN wake capabilities enable remote wake-up of the computer through a network. The
LAN subsystem network adapter monitors network traffic at the Media Independent
Interface. The board supports LAN wake capabilities with ACPI in the following ways:
• By Ping
• By Magic Packet
Upon detecting the configured wake packet type, the LAN subsystem asserts a wake-
up signal that powers up the computer.

Intel D525MW Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Single-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	4 GB
Supported memory clock speeds	800, 1066 MHz
Product family	Desktop board
Product series	Intel® Desktop Boards with Intel Atom® Processors
Processor socket	-
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
Parallel ports quantity	1
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® NM10 Express
Audio output channels	5.1 channels
Motherboard chipset ID	47610
Motherboard form factor	mini ITX
Motherboard chipset family	Intel
Compatible operating systems	Windows XP, Vista, 7
Parallel processing technology support	Not supported
Networking features	10/100/1000
Audio channels	6
Graphics output	VGA
Motherboard ARK ID	48952
Discrete graphics card model	None
Commodity Classification Automated Tracking System (CCATS)	NA
Status	Discontinued
Form factor	Mini-ITX
Last change	63903513
Launch date	Q4'10
USB ports quantity	7
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Harmonized System (HS) code	8471500150

Weight and Dimensions

Width	- mm
