Intel D525MW User Manual

Intel Desktop Board D525MW and Intel Desktop Board D525MWV Technical Product
Specification
56
Table 28. Thermal Considerations for Components
Component Maximum Case Temperature
Intel Atom processor 99
o
C
Processor voltage regulator area 85
o
C
Intel NM10 Express Chipset 113
o
C
Memory SO-DIMM 85
o
C
For information about
Refer to
Processor datasheets and specification updates Section 1.2, page 16
2.6.1 Passive Heatsink Design in a Passive System
Environment
This section highlights important guidelines and related thermal boundary conditions
for passive heatsink design in a passive system environment. Passive heatsink
describes a thermal solution without a fan attached. Passive system environment
describes a chassis with either a power supply fan or a built-in chassis fan.
This information should be used in conjunction with the Thermal/Mechanical
Specifications and Design Guidelines (TMSDG) published for Intel
®
Atom™ D400 and
D500 Series processors. The TMSDG contains detailed package information and
thermal mechanical specifications for the processors. The TMSDG also contains
information on how to enable a completely fanless design provided the right usage
scenario and boundary conditions are observed for optimal thermal design. While the
TMSDG has a section on thermal design for passive system environments
(pages 29-30), the information in this section can also be used to complement the
TMSDG.
2.6.1.1 Definition of Terms
Term Description
T
A
The measured ambient temperature locally surrounding the processor. The ambient
temperature should be measured just upstream of a passive heatsink.
T
J
Processor junction temperature.
Ψ
JA
Junction-to-ambient thermal characterization parameter (psi). A measure of thermal solution
performance using total package power. Defined as (T
J
- T
A
)/TDP.
Note: Heat source must be specified for Ψ measurements.
TIM Thermal Interface Material: the thermally conductive compound between the heatsink and the
processor die surface. This material fills the air gaps and voids, and enhances the transfer of the heat
from the processor die surface to the heatsink.
TDP Thermal Design Power: a power dissipation target based on worst-case applications. Thermal
solutions should be designed to dissipate the thermal design power.
T
A
external The measured external ambient temperature surrounding the chassis. The external ambient
temperature should be measured just upstream of the chassis inlet vent.

Intel D525MW Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Single-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	4 GB
Supported memory clock speeds	800, 1066 MHz
Product family	Desktop board
Product series	Intel® Desktop Boards with Intel Atom® Processors
Processor socket	-
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
Parallel ports quantity	1
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® NM10 Express
Audio output channels	5.1 channels
Motherboard chipset ID	47610
Motherboard form factor	mini ITX
Motherboard chipset family	Intel
Compatible operating systems	Windows XP, Vista, 7
Parallel processing technology support	Not supported
Networking features	10/100/1000
Audio channels	6
Graphics output	VGA
Motherboard ARK ID	48952
Discrete graphics card model	None
Commodity Classification Automated Tracking System (CCATS)	NA
Status	Discontinued
Form factor	Mini-ITX
Last change	63903513
Launch date	Q4'10
USB ports quantity	7
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Harmonized System (HS) code	8471500150

Weight and Dimensions

Width	- mm
