Intel Desktop Board D525MW and Intel Desktop Board D525MWV Technical Product
Specification
62
Table 32 lists the BIOS Setup program menu features.
Table 32. BIOS Setup Program Menu Bar
Maintenance Main Advanced Security Power Boot Exit
Clears
passwords and
displays
processor
information
Displays
processor
and memory
configuration
Configures
advanced
features
available
through the
chipset
Sets
passwords
and security
features
Configures
power
management
features and
power states
options
Selects boot
options
Saves or
discards
changes to
Setup
program
options
Table 33 lists the function keys available for menu screens.
Table 33. BIOS Setup Program Function Keys
BIOS Setup Program
Function Key Description
<←> or <→>
Selects a different menu screen (Moves the cursor left or right)
<
↑
> or <
↓
>
Selects an item (Moves the cursor up or down)
<Enter> Executes command or selects the submenu
<F9> Load the default configuration values for the current menu
<F10> Save the current values and exits the BIOS Setup program
<Esc> Exits the menu
3.2 BIOS Flash Memory Organization
The Serial Peripheral Interface Flash Memory (SPI Flash) includes an 8 Mbit (1024 KB)
flash memory device.
3.3 Resource Configuration
3.3.1 PCI* Autoconfiguration
The BIOS can automatically configure PCI devices. PCI devices may be onboard or
add-in cards. Autoconfiguration lets a user insert or remove PCI cards without having
to configure the system. When a user turns on the system after adding a PCI card, the
BIOS automatically configures interrupts, the I/O space, and other system resources.
Any interrupts set to Available in Setup are considered to be available for use by the
add-in card.

Intel D525MW Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Single-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	4 GB
Supported memory clock speeds	800, 1066 MHz
Product family	Desktop board
Product series	Intel® Desktop Boards with Intel Atom® Processors
Processor socket	-
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
Parallel ports quantity	1
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® NM10 Express
Audio output channels	5.1 channels
Motherboard chipset ID	47610
Motherboard form factor	mini ITX
Motherboard chipset family	Intel
Compatible operating systems	Windows XP, Vista, 7
Parallel processing technology support	Not supported
Networking features	10/100/1000
Audio channels	6
Graphics output	VGA
Motherboard ARK ID	48952
Discrete graphics card model	None
Commodity Classification Automated Tracking System (CCATS)	NA
Status	Discontinued
Form factor	Mini-ITX
Last change	63903513
Launch date	Q4'10
USB ports quantity	7
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Harmonized System (HS) code	8471500150
