Intel D525MW User Manual

Intel Desktop Board D525MW and Intel Desktop Board D525MWV Technical Product
Specification
14
Table 2. Board Components Shown in Figure 1
Item/callout
from Figure 1 Description
A
Back panel connectors
B
LVDS inverter panel voltage selection jumper (D525MWV only)
C
Serial port header
D
LVDS inverter power voltage selection jumper (D525MWV only)
E
LVDS inverter power connector (D525MWV only)
F
LVDS panel connector (D525MWV only)
G
Processor core power connector (2 x 2)
H
Intel Atom processor
I
Power connector (2 x 12)
J
SO-DIMM channel A socket, DIMM 0
K
SO-DIMM channel A socket, DIMM 1
L
Battery
M
SATA connector 1
N
SATA connector 0
O
Front panel USB header (black)
P
Front panel header
Q
Standby power LED
R
BIOS setup configuration jumper block
S
PCI Express x1 Mini Card connector
T
Intel NM10 Express Chipset
U Front Panel Wireless Activity LED Header
V
Front panel USB header supports Intel Z-U130 USB Solid-State
Drive or compatible device (brown-colored)
W
PCI conventional bus connector
X
S/PDIF header
Y
Chassis fan header
Z
Front panel audio header

Intel D525MW Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Single-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	4 GB
Supported memory clock speeds	800, 1066 MHz
Product family	Desktop board
Product series	Intel® Desktop Boards with Intel Atom® Processors
Processor socket	-
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
Parallel ports quantity	1
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® NM10 Express
Audio output channels	5.1 channels
Motherboard chipset ID	47610
Motherboard form factor	mini ITX
Motherboard chipset family	Intel
Compatible operating systems	Windows XP, Vista, 7
Parallel processing technology support	Not supported
Networking features	10/100/1000
Audio channels	6
Graphics output	VGA
Motherboard ARK ID	48952
Discrete graphics card model	None
Commodity Classification Automated Tracking System (CCATS)	NA
Status	Discontinued
Form factor	Mini-ITX
Last change	63903513
Launch date	Q4'10
USB ports quantity	7
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Harmonized System (HS) code	8471500150

Weight and Dimensions

Width	- mm
