Intel D525MW User Manual

iii
Board Identification Information
Basic Desktop Board D525MW Identification Information
AA Revision
BIOS Revision
Notes
E93080-300 MWPNT10N.86A.0049 1,2
E93082-300 MWPNT10N.86A.0049 1,2
E93080-301 MWPNT10N.86A.0069 1,2
E93081-301 MWPNT10N.86A.0069 1,2
E93082-301 MWPNT10N.86A.0069 1,2
E93080-400 MWPNT10N.86A.0069 1,2
E93081-400 MWPNT10N.86A.0069 1,2
E93082-400 MWPNT10N.86A.0069 1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The CG82NM10 chipset used on this AA revision consists of the following component:
Device
Stepping
S-Spec Numbers
CG82NM10 B0 SLGXX
Specification Changes or Clarifications
The table below indicates the Specification Changes or Specification Clarifications that
apply to the Intel
®
Desktop Board D525MW.
Specification Changes or Clarifications
Date Type of Change Description of Changes or Clarifications
May 2013 Spec Clarification Added ENERGY STAR Note to Section 5.1.5.
July 2013 Spec Clarification Deleted references to ENERGY STAR.
Errata
Current characterized errata, if any, are documented in a separate Specification
Update. See
http://www.intel.com/content/www/us/en/motherboards/desktop-
motherboards/motherboards.html?wapkw=desktop+boards for the latest
documentation.

Intel D525MW Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Single-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	4 GB
Supported memory clock speeds	800, 1066 MHz
Product family	Desktop board
Product series	Intel® Desktop Boards with Intel Atom® Processors
Processor socket	-
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
Parallel ports quantity	1
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® NM10 Express
Audio output channels	5.1 channels
Motherboard chipset ID	47610
Motherboard form factor	mini ITX
Motherboard chipset family	Intel
Compatible operating systems	Windows XP, Vista, 7
Parallel processing technology support	Not supported
Networking features	10/100/1000
Audio channels	6
Graphics output	VGA
Motherboard ARK ID	48952
Discrete graphics card model	None
Commodity Classification Automated Tracking System (CCATS)	NA
Status	Discontinued
Form factor	Mini-ITX
Last change	63903513
Launch date	Q4'10
USB ports quantity	7
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Harmonized System (HS) code	8471500150

Weight and Dimensions

Width	- mm
