Intel Desktop Board D945GCNL Product Guide
12
Table 2. Desktop Board D945GCNL Components
Label Description
A Front panel audio header
B PCI bus connector 2
C PCI bus connector 1
D PCI Express x1 connector
E PCI Express x16 connector
F Back panel connectors
G 12 V processor core voltage connector (2 x 2 pin )
H Processor fan header (4-pin)
I Rear chassis fan header (3-pin)
J Processor socket
K DIMM 0, Channel A socket
L DIMM 0, Channel B socket
M Chassis intrusion header
N Main power connector (2 x 12 pin)
O Diskette drive connector
P IDE connector
Q Front chassis fan header (3-pin)
R Serial ATA connectors
S Front panel header
T Speaker
U Hi-speed USB 2.0 headers
V Alternate front panel power LED header
W Battery
X BIOS configuration jumper block
Related Links:
Go to the following links for more information about:
• Desktop Board D945GCNL
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• Supported processors
http://www.intel.com/go/FindCPU
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd

Intel D945GCNL - Desktop Board Motherboard Specifications

General

Form Factor	Micro ATX
Socket Type	LGA 775
Memory Type	DDR2
Maximum Memory	4 GB
Graphics	Intel Graphics Media Accelerator 950
USB Ports	8 x USB 2.0
Processor Support	Intel Pentium D, Pentium 4, Celeron D
Audio	Realtek ALC888
LAN	10/100 Ethernet
Expansion Slots	1 x PCIe x16, 2 x PCI
Chipset	Intel 945GC Express Chipset
