9
1 Desktop Board Features
This chapter briefly describes the main features of Intel
®
Desktop Board D945GCNL.
Table 1 summarizes the major features of the desktop b
oard.
Table 1. Feature Summary
Form Factor
microATX (243.84 millimeters [9.60 inches] x 243.84 millimeters
[9.60 inches])
Processor Support for an Intel
®
processor in the LGA775 package
Main Memory
• Two 240-pin, DDR2 1.8 V (only) SDRAM Dual Inline Memory Module
(DIMM) sockets
• 667/533/400 MHz single or dual channel DDR2 SDRAM interface
• Support for up to 2 GB of system memory
Chipset Intel
®
945GC Express Chipset consisting of:
• Intel
®
82945GC Express Chipset Graphics and Memory Controller Hub
(GMCH)
• Intel
®
82801GB I/O Controller Hub (ICH7)
Graphics
• Intel
®
945GC Express Chipset with
Intel
®
Graphics Media Accelerator 950
(Intel
®
GMA 950)
• PCI Express* graphics card support via a PCI Express x16 connector
Audio
• 6-channel (5.1) onboard subsystem, featuring:
― Intel
®
High Definition Audio interface
― Realtek* ALC888 audio codec
Expansion
Capabilities
• One PCI Express x1 connector
• One PCI Express x16 connector
• Two PCI* connectors
Peripheral
Interfaces
• Up to eight USB 2.0 ports
― Four ports routed to the back panel
― Four ports routed to two USB headers
• Four Serial ATA (SATA) channels (3.0 Gb/s), via the ICH7, one device per
channel
• One IDE interface with ATA-66/100 support (two devices)
• One diskette drive interface
• One VGA port
• One parallel port
• One serial port
• PS/2* keyboard and mouse ports
continued
