Desktop Board Features
15
• Back panel audio connectors that are configurable through the audio device
drivers:
― Line in/retasking jack
― Line out/retasking jack
― Mic in/retasking jack
Related Links:
Go to the following link or pages for more information about:
• Audio drivers and utilities http://support.intel.com/support/motherboards/desktop/
• Installing the front panel audio solution, page 41
• The location of a
udio connectors, Figure 21 on page 43
Input/Output (I/O) Controller
The super I/O controller features the following:
• One serial port
• One parallel port with Extended Capabilities Port (ECP) and Enhanced Parallel Port
(EPP) support
• Serial IRQ interface compatible with serialized IRQ support for PCI systems
• PS/2-style mouse and keyboard interfaces
• Interface for one 1.2 MB or 1.44 MB diskette drive
• Intelligent power management, including a programmable wake up event interface
• PCI power management support
LAN Subsystem
The LAN subsystem consists of the following:
• Realtek RTL811B-GR Gigabit Ethernet Controller device for 10/100/1000 Mb/s
Ethernet LAN connectivity
• RJ-45 connector with status indicator LEDs
LAN Subsystem Software
For LAN software and drivers, refer to the D945GCNL link on Intel’s World Wide Web
site at:
http://support.intel.com/support/motherboards/desktop
