Intel ETHEREXPRESS PRO/100 User Manual

Utilities and Applications 5-11
2 Click Preferences.
3 In the Connection window under Connection Type check all
settings for accuracy.
a Winsock: (Default WINSOCK).
b Connect using:
c Phone #:
d Port:
e Port speed:
f Dial type:
Modify any of the above settings are not valid.
4 To modify the modem type, click Define Modem, highlight Intel as
manufacturer and the EtherExpress PRO/100 LAN+Modem PC
Card model.
Note
The default initialization string should suffice. To modify your
initialization string, click Define Modem and enter the new
initialization string in the Initialization section.
5 Click OK to save configuration and exit.
LapLink version 6.0
To set up the Intel modem or modify the present configuration:
1 In the Control Panel, click the Modem icon to access the Port Setup
window.
2 In the Port Setup Screen.
a Click the communications port that corresponds to the one
assigned to the modem.
b Select Modem under Type.

Intel ETHEREXPRESS PRO/100 Specifications

General

Device Type	Network adapter
Form Factor	Plug-in card
Data Link Protocol	Ethernet, Fast Ethernet
Data Transfer Rate	100 Mbps
Compliant Standards	IEEE 802.3, IEEE 802.3u
Connector Type	RJ-45
Bus Type	PCI
Chipset	Intel 82557
Full Duplex Support	Yes
Wake-on-LAN Support	Yes
Ports	1 x RJ45
Data Rate	10 Mbps / 100 Mbps
Operating Systems Supported	Linux, Windows
