Intel Itanium 2 Processor - Page 49

Datasheet 49
Pinout Specifications
ID1# IDA1#/IP1# AB02 IN
ID2# IDA2#/DHIT# AC03 IN
ID3# IDA3#/IDB3# AA03 IN
ID4# IDA4#/IDB4# AD04 IN
ID5# IDA5#/IDB5# AB04 IN
ID6# IDA6#/IDB6# AE05 IN
ID7# IDA7#/IDB7# AC05 IN
ID8# IDA8#/IDB8# AD06 IN
ID9# IDA9#/IDB9# AB06 IN
IDS# IDS# AC07 IN
IGNNE# IGNNE# AG23 IN
INIT# INIT# AF08 IN
LINT0 INT AF22 IN
LINT1 NMI AF24 IN
LOCK# LOCK# AE15 IN/OUT
N/C A04
N/C AB16
N/C AC17
N/C AC21
N/C AD18
N/C AE17
N/C AG05
N/C AG11
N/C AG17
N/C AG19
N/C AG21
N/C AH05
N/C AH11
N/C AH17
N/C AH19
N/C AH21
N/C B04
N/C B06
N/C B08
N/C B14
N/C B16
N/C B20
N/C C03
N/C C13
N/C C15
N/C C25
Table 3-1. Pin/Signal Information Sorted by Pin Name (Sheet 12 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
