Pinout Specifications
N/C K02
N/C K12
N/C K14
N/C K24
N/C U05
N/C U11
OUTEN OUTEN AF04 IN Power pod signal
PMI# PMI# AE25 IN
PPODGD# PPODGD# AF20 OUT Power pod signal
PWRGOOD PWRGOOD AH15 IN
REQ0# REQA0#/LEN0# AE09 IN/OUT
REQ1# WSNP#, D/C#/LEN1# AF10 IN/OUT
REQ2# REQA2#/ REQB2# AD10 IN/OUT
REQ3# ASZ0#/DSZ0# AE11 IN/OUT
REQ4# ASZ1#/DSZ1# AF12 IN/OUT
REQ5# REQ5# AD12 IN/OUT
RESET# RESET# AD20 IN
RP# RP# AC13 IN/OUT
RS0# RS0# AE07 IN
RS1# RS1# AD08 IN
RS2# RS2# AB08 IN
RSP# RSP# AF06 IN
SBSY# SBSY# AE13 IN/OUT
SBSY0# SBSY_C1# AA13 OUT
SBSY1# SBSY_C2# AC19 OUT
SMA0 SMA0 B18 IN SMBus signal
SMA1 SMA1 A17 IN SMBus signal
SMA2 SMA2 A15 IN SMBus signal
SMSC SMSC B24 IN SMBus signal
SMSD SMSD B22 IN/OUT SMBus signal
SMWP SMWP A21 IN SMBus signal
STBN0# STBN0# F04 IN/OUT
STBN1# STBN1# N05 IN/OUT
STBN2# STBN2# F10 IN/OUT
STBN3# STBN3# N11 IN/OUT
STBN4# STBN4# F16 IN/OUT
STBN5# STBN5# N17 IN/OUT
STBN6# STBN6# F22 IN/OUT
STBN7# STBN7# N23 IN/OuT
STBP0# STBP0# E05 IN/OUT
STBP1# STBP1# M04 IN/OUT
Table 3-1. Pin/Signal Information Sorted by Pin Name (Sheet 13 of 15)
