Intel Itanium 2 Processor - Page 54

54 Datasheet
Pinout Specifications
N/C B20
GND GND B21 IN
SMSD SMSD B22 IN/OUT SMBus signal
GND GND B23 IN
SMSC SMSC B24 IN SMBus signal
GND GND B25 IN
VCTERM VCTERM C01 IN
GND GND C02 IN
N/C C03
VCTERM VCTERM C04 IN
D002# D02# C05 IN/OUT
GND GND C06 IN
D000# D00# C07 IN/OUT
VCTERM VCTERM C08 IN
D035# D35# C09 IN/OUT
GND GND C10 IN
D033# D33# C11 IN/OUT
VCTERM VCTERM C12 IN
N/C C13
GND GND C14 IN
N/C C15
VCTERM VCTERM C16 IN
D073# D73# C17 IN/OUT
GND GND C18 IN
D070# D70# C19 IN/OUT
VCTERM VCTERM C20 IN
D099# D99# C21 IN/OUT
GND GND C22 IN
D097# D97# C23 IN/OUT
VCTERM VCTERM C24 IN
N/C C25
GND GND D01 IN
D004# D04# D02 IN/OUT
GND GND D03 IN
D003# D03# D04 IN/OUT
GND GND D05 IN
D005# D05# D06 IN/OUT
GND GND D07 IN
D037# D37# D08 IN/OUT
GND GND D09 IN
D034# D34# D10 IN/OUT
Table 3-2. Pin/Signal Information Sorted by Pin Location (Sheet 2 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
