Intel Itanium 2 Processor - Page 55

Datasheet 55
Pinout Specifications
GND GND D11 IN
D036# D36# D12 IN/OUT
GND GND D13 IN
D065# D65# D14 IN/OUT
GND GND D15 IN
D066# D66# D16 IN/OUT
GND GND D17 IN
D064# D64# D18 IN/OUT
GND GND D19 IN
D102# D102# D20 IN/OUT
GND GND D21 IN
D098# D98# D22 IN/OUT
GND GND D23 IN
D104# D104# D24 IN/OUT
GND GND D25 IN
VCTERM VCTERM E02 IN
D001# D01# E03 IN/OUT
GND GND E04 IN
STBP0# STBP0# E05 IN/OUT
VCTERM VCTERM E06 IN
D010# D10# E07 IN/OUT
GND GND E08 IN
D040# D40# E09 IN/OUT
VCTERM VCTERM E10 IN
STBP2# STBP2# E11 IN/OUT
GND GND E12 IN
D039# D39# E13 IN/OUT
VCTERM VCTERM E14 IN
D067# D67# E15 IN/OUT
GND GND E16 IN
STBP4# STBP4# E17 IN/OUT
VCTERM VCTERM E18 IN
D074# D74# E19 IN/OUT
GND GND E20 IN
D096# D96# E21 IN/OUT
VCTERM VCTERM E22 IN
STBP6# STBP6# E23 IN/OUT
GND GND E24 IN
D100# D100# E25 IN/OUT
GND GND F01 IN
D007# D07# F02 IN/OUT
Table 3-2. Pin/Signal Information Sorted by Pin Location (Sheet 3 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
