Intel Itanium 2 Processor - Page 56

56 Datasheet
Pinout Specifications
GND GND F03 IN
STBN0# STBN0# F04 IN/OUT
GND GND F05 IN
D006# D06# F06 IN/OUT
GND GND F07 IN
D045# D45# F08 IN/OUT
GND GND F09 IN
STBN2# STBN2# F10 IN/OUT
GND GND F11 IN
D044# D44# F12 IN/OUT
GND GND F13 IN
D068# D68# F14 IN/OUT
GND GND F15 IN
STBN4# STBN4# F16 IN/OUT
GND GND F17 IN
D069# D69# F18 IN/OUT
GND GND F19 IN
D106# D106# F20 IN/OUT
GND GND F21 IN
STBN6# STBN6# F22 IN/OUT
GND GND F23 IN
D103# D103# F24 IN/OUT
GND GND F25 IN
VCTERM VCTERM G01 IN
GND GND G02 IN
D014# D14# G03 IN/OUT
VCTERM VCTERM G04 IN
D008# D08# G05 IN/OUT
D015# D15# G07 IN/OUT
VCTERM VCTERM G08 IN
D038# D38# G09 IN/OUT
D041# D41# G11 IN/OUT
VCTERM VCTERM G12 IN
D043# D43# G13 IN/OUT
D071# D71# G15 IN/OUT
VCTERM VCTERM G16 IN
D072# D72# G17 IN/OUT
D079# D79# G19 IN/OUT
VCTERM VCTERM G20 IN
D101# D101# G21 IN/OUT
D108# D108# G23 IN/OUT
Table 3-2. Pin/Signal Information Sorted by Pin Location (Sheet 4 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
