Pinout Specifications
D120# D120# P24 IN/OUT
GND GND P25 IN
VCTERM VCTERM R01 IN
GND GND R02 IN
D025# D25# R03 IN/OUT
VCTERM VCTERM R04 IN
D029# D29# R05 IN/OUT
D031# D31# R07 IN/OUT
VCTERM VCTERM R08 IN
D063# D63# R09 IN/OUT
D060# D60# R11 IN/OUT
VCTERM VCTERM R12 IN
D059# D59# R13 IN/OUT
D092# D92# R15 IN/OUT
VCTERM VCTERM R16 IN
D089# D89# R17 IN/OUT
D090# D90# R19 IN/OUT
VCTERM VCTERM R20 IN
D124# D124# R21 IN/OUT
D126# D126# R23 IN/OUT
VCTERM VCTERM R24 IN
D121# D121# R25 IN/OUT
GND GND T01 IN
D030# D30# T02 IN/OUT
GND GND T03 IN
DEP03# DEP3# T04 IN/OUT
GND GND T05 IN
DEP02# DEP2# T06 IN/OUT
GND GND T07 IN
DEP06# DEP6# T08 IN/OUT
GND GND T09 IN
DEP07# DEP7# T10 IN/OUT
GND GND T11 IN
D062# D62# T12 IN/OUT
GND GND T13 IN
D094# D94# T14 IN/OUT
GND GND T15 IN
DEP11# DEP11# T16 IN/OUT
GND GND T17 IN
DEP10# DEP10# T18 IN/OUT
GND GND T19 IN
Table 3-2. Pin/Signal Information Sorted by Pin Location (Sheet 9 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
