62 Datasheet
Pinout Specifications
DEP14# DEP14# T20 IN/OUT
GND GND T21 IN
DEP15# DEP15# T22 IN/OUT
GND GND T23 IN
D123# D123# T24 IN/OUT
GND GND T25 IN
VCTERM VCTERM U02 IN
A005# AA05#/EXF2# U03 IN/OUT
GND GND U04 IN
N/C U05
VCTERM VCTERM U06 IN
A009# AA09#/BE1# U07 IN/OUT
A018# AA18#/DID2# U09 IN/OUT
VCTERM VCTERM U10 IN
N/C U11
A016# AA16#/DID0# U13 IN/OUT
VCTERM VCTERM U14 IN
A028# AA28#/xTPRValue1# U15 IN/OUT
BNR# BNR# U17 IN/OUT
VCTERM VCTERM U18 IN
A027# AA27#/xTPRValue0# U19 IN/OUT
GND GND U20 IN
A048# AA48#/AB48# U21 IN/OUT
VCTERM VCTERM U22 IN
A042# AA42#/AB42# U23 IN/OUT
GND GND U24 IN
VCTERM VCTERM U25 IN
GND GND V01 IN
A004# AA04#/EXF1# V02 IN/OUT
GND GND V03 IN
A010# AA10#/BE2# V04 IN/OUT
GND GND V05 IN
A003# AA03#/EXF0# V06 IN/OUT
GND GND V07 IN
A015# AA15#/BE7# V08 IN/OUT
GND GND V09 IN
A020# AA20#/DID4# V10 IN/OUT
GND GND V11 IN
A019# AA19#/DID3# V12 IN/OUT
GND GND V13 IN
A031# AA31#/xTPRDisable# V14 IN/OUT
Table 3-2. Pin/Signal Information Sorted by Pin Location (Sheet 10 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
