System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
100 Intel order number G90620-002 Revision 1.1
10.3 Button Sensor
The BMC logs when the front panel power and reset buttons get pressed. This is purely for informational purposes and these events
do not indicate errors.
Table 76: Button Sensor Typical Characteristics
Byte
Field
Description
11
Sensor Type
14h = Button / Switch
12
Sensor Number
09h
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 6Fh (Sensor Specific)
14
Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset
0h = Power Button
2h = Reset Button
15
Event Data 2
Not used
16
Event Data 3
Not used
