-Swap Controller Backplane Events
System Event Log Troubleshooting Guide for EPSD
Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/160
0/1400 Product Families
114
Intel order number G90620-
00
2
Revision 1.1
Byte
Field
Description
15
Event Data 2
Not used
16
Event Data 3
Not used
12.3.1
HSC
Health Sensor
–
Next Steps
Ensure that all connections to the
HSC are well seated.
Cross test with another HSC. If the issue remain
s with the HSC, replace the HSC, other
wise start cross testing all interconne
ctions.
123
125
Table of Contents
Default Chapter
2
Revision History
2
Table of Contents
4
1 Introduction
11
Purpose
11
Industry Standard
12
Intelligent Platform Management Interface (IPMI)
12
Baseboard Management Controller (BMC)
12
Intel ® Intelligent Power Node Manager Version 2.0
13
2 Basic Decoding of a SEL Record
14
Default Values in the SEL Records
14
Table 1. SEL Record Format
14
Table 2: Event Request Message Event Data Field Contents
17
Table 3: OEM SEL Record (Type C0H-Dfh)
18
Table 4: OEM SEL Record (Type E0H-Ffh)
19
Notes on SEL Logs and Collecting SEL Information
20
Examples of Decoding BIOS Timestamp Events
20
Example of Decoding a PCI Express* Correctable Error Events
21
Example of Decoding a Power Supply Predictive Failure Event
22
3 Sensor Cross Reference List
23
BMC Owned Sensors (GID = 0020H)
23
Table 5: BMC Owned Sensors
23
BIOS POST Owned Sensors (GID = 0001H)
34
BIOS SMI Handler Owned Sensors (GID = 0033H)
34
Table 6: BIOS POST Owned Sensors
34
Table 7: BIOS SMI Handler Owned Sensors
34
Node Manager / ME Firmware Owned Sensors (GID = 002Ch or 602Ch)
35
Table 8: Management Engine Firmware Owned Sensors
35
Microsoft* os Owned Events (GID = 0041)
36
Linux* Kernel Panic Events (GID = 0021)
36
Table 9: Microsoft* os Owned Events
36
Table 10: Linux* Kernel Panic Events
36
4 Power Subsystems
37
Threshold-Based Voltage Sensors
37
Table 11: Threshold-Based Voltage Sensors Typical Characteristics
37
Table 12: Threshold-Based Voltage Sensors Event Triggers - Description
38
Table 13: Threshold-Based Voltage Sensors - Next Steps
38
Voltage Regulator Watchdog Timer Sensor
43
Voltage Regulator Watchdog Timer Sensor - Next Steps
44
Power Unit
44
Power Unit Status Sensor
44
Table 14: Voltage Regulator Watchdog Timer Sensor Typical Characteristics
44
Table 15: Power Unit Status Sensors Typical Characteristics
45
Table 16: Power Unit Status Sensor - Sensor Specific Offsets - Next Steps
45
Power Unit Redundancy Sensor
46
Table 17: Power Unit Redundancy Sensors Typical Characteristics
46
Node Auto Shutdown Sensor
47
Table 18: Power Unit Redundancy Sensor - Event Trigger Offset - Next Steps
47
Table 19: Node Auto Shutdown Sensor Typical Characteristics
47
Power Supply
48
Power Supply Status Sensors
48
Table 20: Power Supply Status Sensors Typical Characteristics
48
Table 21: Power Supply Status Sensor - Sensor Specific Offsets - Next Steps
49
Power Supply Power in Sensors
51
Table 22: Power Supply Power in Sensors Typical Characteristics
51
Table 23: Power Supply Power in Sensor - Event Trigger Offset - Next Steps
51
Power Supply Current out % Sensors
52
Table 24: Power Supply Current out % Sensors Typical Characteristics
52
Table 25: Power Supply Current out % Sensor - Event Trigger Offset - Next Steps
52
Power Supply Temperature Sensors
53
Table 26: Power Supply Temperature Sensors Typical Characteristics
53
Table 27: Power Supply Temperature Sensor - Event Trigger Offset - Next Steps
53
Power Supply Fan Tachometer Sensors
54
Table 28: Power Supply Fan Tachometer Sensors Typical Characteristics
54
5 Cooling Subsystem
55
Fan Sensors
55
Fan Tachometer Sensors
55
Table 29: Fan Tachometer Sensors Typical Characteristics
55
Fan Presence and Redundancy Sensors
56
Table 30: Fan Tachometer Sensor - Event Trigger Offset - Next Steps
56
Table 31: Fan Presence Sensors Typical Characteristics
56
Table 32: Fan Presence Sensors - Event Trigger Offset - Next Steps
57
Table 33: Fan Redundancy Sensors Typical Characteristics
57
Table 34: Fan Redundancy Sensor - Event Trigger Offset - Next Steps
58
Temperature Sensors
59
Threshold-Based Temperature Sensors
59
Table 35: Temperature Sensors Typical Characteristics
59
Table 36: Temperature Sensors Event Triggers - Description
60
Table 37: Temperature Sensors - Next Steps
60
Thermal Margin Sensors
61
Table 38: Thermal Margin Sensors Typical Characteristics
61
Table 39: Thermal Margin Sensors Event Triggers - Description
62
Table 40: Thermal Margin Sensors - Next Steps
62
Processor Thermal Control Sensors
63
Table 41: Processor Thermal Control Sensors Typical Characteristics
63
Table 42: Processor Thermal Control Sensors Event Triggers - Description
64
Processor DTS Thermal Margin Sensors
65
Discrete Thermal Sensors
65
Table 43: Processor DTS Thermal Margin Sensors Typical Characteristics
65
Table 44: Discrete Thermal Sensors Typical Characteristics
66
Table 45: Discrete Thermal Sensors - Next Steps
66
DIMM Thermal Trip Sensors
67
Table 46: DIMM Thermal Trip Typical Characteristics
67
System Air Flow Monitoring Sensor
68
6 Processor Subsystem
69
Processor Status Sensor
69
Table 47: Process Status Sensors Typical Characteristics
69
Table 48: Processor Status Sensors - Next Steps
70
Catastrophic Error Sensor
71
Table 49: Catastrophic Error Sensor Typical Characteristics
71
Table 50: Catastrophic Error Sensor - Event Data 2 Values - Next Steps
71
CPU Missing Sensor
72
Table 51: CPU Missing Sensor Typical Characteristics
72
CPU Missing Sensor - Next Steps
73
Quick Path Interconnect Sensors
73
QPI Link Width Reduced Sensor
73
Table 52: QPI Link Width Reduced Sensor Typical Characteristics
73
QPI Correctable Error Sensor
74
Table 53: QPI Correctable Error Sensor Typical Characteristics
74
QPI Fatal Error and Fatal Error #2
75
Table 54: QPI Fatal Error Sensor Typical Characteristics
75
Table 55: QPI Fatal #2 Error Sensor Typical Characteristics
76
Processor ERR2 Timeout Sensor
77
Processor ERR2 Timeout - Next Steps
78
Processor MSID Mismatch Sensor
78
Table 56: Processor ERR2 Timeout Sensor Typical Characteristics
78
Processor MSID Mismatch Sensor - Next Steps
79
Table 57: Processor MSID Mismatch Sensor Typical Characteristics
79
7 Memory Subsystem
80
Memory RAS Configuration Status
80
Table 58: Memory RAS Configuration Status Sensor Typical Characteristics
80
Table 59: Memory RAS Configuration Status Sensor - Event Trigger Offset - Next Steps
81
Memory RAS Mode Select
82
Table 60: Memory RAS Mode Select Sensor Typical Characteristics
82
Mirroring Redundancy State
83
Table 61: Mirroring Redundancy State Sensor Typical Characteristics
83
Mirroring Redundancy State Sensor - Next Steps
84
Sparing Redundancy State
84
Table 62: Sparing Redundancy State Sensor Typical Characteristics
85
Sparing Redundancy State Sensor - Next Steps
86
ECC and Address Parity
86
Memory Correctable and Uncorrectable ECC Error
86
Table 63: Correctable and Uncorrectable ECC Error Sensor Typical Characteristics
86
Memory Address Parity Error
88
Table 65: Address Parity Error Sensor Typical Characteristics
88
8 PCI Express* and Legacy PCI Subsystem
91
PCI Express* Errors
91
Legacy PCI Errors
91
Table 66: Legacy PCI Error Sensor Typical Characteristics
91
PCI Express* Fatal Errors and Fatal Error #2
92
Table 67: PCI Express* Fatal Error Sensor Typical Characteristics
92
Table 68: PCI Express* Fatal Error #2 Sensor Typical Characteristics
93
PCI Express* Correctable Errors
94
Table 69: PCI Express* Correctable Error Sensor Typical Characteristics
95
9 System BIOS Events
97
System Events
97
System Boot
97
Timestamp Clock Synchronization
97
Table 70: System Event Sensor Typical Characteristics
98
System Firmware Progress (Formerly Post Error)
99
System Firmware Progress (Formerly Post Error) - Next Steps
99
Table 71: POST Error Sensor Typical Characteristics
99
Table 72: POST Error Codes
100
10 Chassis Subsystem
107
Physical Security
107
Chassis Intrusion
107
LAN Leash Lost
107
Table 73: Physical Security Sensor Typical Characteristics
107
FP (NMI) Interrupt
108
Table 74: Physical Security Sensor Event Trigger Offset - Next Steps
108
FP (NMI) Interrupt - Next Steps
109
Table 75: FP (NMI) Interrupt Sensor Typical Characteristics
109
Button Sensor
110
Table 76: Button Sensor Typical Characteristics
110
11 Miscellaneous Events
111
IPMI Watchdog
111
Table 77: IPMI Watchdog Sensor Typical Characteristics
111
SMI Timeout
112
Table 78: IPMI Watchdog Sensor Event Trigger Offset - Next Steps
112
Table 79: SMI Timeout Sensor Typical Characteristics
112
SMI Timeout - Next Steps
113
System Event Log Cleared
113
Table 80: System Event Log Cleared Sensor Typical Characteristics
113
System Event - PEF Action
114
System Event - PEF Action - Next Steps
114
Table 81: System Event - PEF Action Sensor Typical Characteristics
114
BMC Watchdog Sensor
115
BMC Watchdog Sensor - Next Steps
115
Table 82: BMC Watchdog Sensor Typical Characteristics
115
BMC FW Health Sensor
116
BMC FW Health Sensor - Next Steps
116
Table 83: BMC FW Health Sensor Typical Characteristics
116
Firmware Update Status Sensor
117
Table 84: Firmware Update Status Sensor Typical Characteristics
117
Add-In Module Presence Sensor
118
Add-In Module Presence - Next Steps
118
Table 85: Add-In Module Presence Sensor Typical Characteristics
118
Intel ® Xeon Phi ™ Coprocessor Management Sensors
119
Intel ® Xeon Phi ™ Coprocessor (MIC) Thermal Margin Sensors
119
Intel ® Xeon Phi ™ Coprocessor (MIC) Status Sensors
119
Table 86: MIC Status Sensors - Typical Characteristics
119
12 Hot-Swap Controller Backplane Events
121
HSC Backplane Temperature Sensor
121
Table 87: HSC Backplane Temperature Sensor Typical Characteristics
121
Hard Disk Drive Monitoring Sensor
122
Table 88: HSC Backplane Temperature Sensor - Event Trigger Offset - Next Steps
122
Table 89: Hard Disk Drive Monitoring Sensor Typical Characteristics
122
Hot-Swap Controller Health Sensor
123
Table 90: Hard Disk Drive Monitoring Sensor - Event Trigger Offset - Next Steps
123
Table 91: HSC Health Sensor Typical Characteristics
123
HSC Health Sensor - Next Steps
124
13 Manageability Engine (ME) Events
125
ME Firmware Health Event
125
ME Firmware Health Event - Next Steps
125
Table 92: ME Firmware Health Event Sensor Typical Characteristics
125
Table 93: ME Firmware Health Event Sensor - Next Steps
126
Node Manager Exception Event
127
Node Manager Exception Event - Next Steps
127
Table 94: Node Manager Exception Sensor Typical Characteristics
127
Node Manager Health Event
128
Table 95: Node Manager Health Event Sensor Typical Characteristics
128
Node Manager Health Event - Next Steps
129
Node Manager Operational Capabilities Change
130
Table 96: Node Manager Operational Capabilities Change Sensor Typical Characteristics
130
Node Manager Operational Capabilities Change - Next Steps
131
Node Manger Alert Threshold Exceeded
132
Table 97: Node Manager Alert Threshold Exceeded Sensor Typical Characteristics
132
Node Manger Alert Threshold Exceeded - Next Steps
133
14 Microsoft Windows* Records
134
Boot up Event Records
134
Table 98: Boot up Event Record Typical Characteristics
134
Table 99: Boot up OEM Event Record Typical Characteristics
135
Shutdown Event Records
136
Table 100: Shutdown Reason Code Event Record Typical Characteristics
136
Table 101: Shutdown Reason OEM Event Record Typical Characteristics
136
Table 102: Shutdown Comment OEM Event Record Typical Characteristics
137
Bug Check / Blue Screen Event Records
138
Table 103: Bug Check/Blue Screen - os Stop Event Record Typical Characteristics
138
Table 104: Bug Check/Blue Screen Code OEM Event Record Typical Characteristics
139
15 Linux* Kernel Panic Records
140
Table 105: Linux* Kernel Panic Event Record Characteristics
140
Table 106: Linux* Kernel Panic String Extended Record Characteristics
141
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Intel S2600GZ and is the answer not in the manual?
Ask a question
Intel S2600GZ Specifications
General
Brand
Intel
Model
S2600GZ
Category
Motherboard
Language
English
Related product manuals
Intel S2600IP
186 pages
Intel S2400SC
161 pages
Intel S1200BT
122 pages
Intel S1400FP
141 pages
S5000XVN - Workstation Board Motherboard
88 pages
S3200SHV - Entry Server Board Motherboard
128 pages
630 - Pentium 4 630 3.0GHz 800MHz 2MB Socket 775 CPU
54 pages
Intel DH67BL
94 pages
Intel DH61BE
88 pages
Intel DH55HC
86 pages
Intel DG41TY
88 pages
Intel D945GNT
74 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
