System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
Miscellaneous Events
Revision 1.1 Intel order number G90620-002 101
11. Miscellaneous Events
The miscellaneous events section addresses sensors not easily grouped with other sensor types.
11.1 IPMI Watchdog
EPSD server systems support an IPMI watchdog timer, which can check to see whether the OS is still responsive. The timer is
disabled by default, and has to be enabled manually. It then requires an IPMI-aware utility in the operating system that will reset the
timer before it expires. If the timer does expire, the BMC can take action if it is configured to do so (reset, power down, power cycle,
or generate a critical interrupt).
Table 77: IPMI Watchdog Sensor Typical Characteristics
Byte
Field
Description
11
Sensor Type
23h = Watchdog 2
12
Sensor Number
03h
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 6Fh (Sensor Specific)
14
Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset as describe in Table 78
15
Event Data 2
Not used
16
Event Data 3
Not used
