System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
Sensor Cross Reference List
Revision 1.1 Intel order number G90620-002 23
Sensor
Number
Sensor Name
Details Section
Next Steps
E4h
Baseboard +1.35V P1 Low Voltage
Memory AB VDDQ
(BB +1.35 P1LV AB)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
E5h
Baseboard +1.35V P1 Low Voltage
Memory CD VDDQ
(BB +1.35 P1LV CD)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
E6h
Baseboard +1.35V P2 Low Voltage
Memory AB VDDQ
(BB +1.35 P2LV AB)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
E7h
Baseboard +1.35V P2 Low Voltage
Memory CD VDDQ
(BB +1.35 P2LV CD)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
EAh
Baseboard +3.3V Riser 1 Power
Good
(BB +3.3 RSR1 PGD)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
EBh
Baseboard +3.3V Riser 2 Power
Good
(BB +3.3 RSR2 PGD)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
ECh
Baseboard +0.9V
(BB 0.9V Core IB)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
EDh
Baseboard +1.8V
(BB 1.8V IB I/O)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
EEh
Baseboard +1.1V
(BB 1.1V PCH)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
EFh
Baseboard +1.2V
(BB +1.2V IB)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
F0h-FEh
Hard Disk Drive 0 -14 Status
(HDD 0 – 14 Status)
Hard Disk Drive Monitoring
Sensor
Table 90: Hard Disk Drive Monitoring Sensor - Event Trigger Offset – Next
Steps
