Miscellaneous Events
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
110 Intel order number G90620-002 Revision 1.1
Byte
Field
Description
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 70h (OEM defined)
14
Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset
Refer to the latest Intel
®
Xeon Phi
™
Coprocessor Adapter specification.
15
Event Data 2
Not used
16
Event Data 3
Not used
11.9.2.1 Intel
®
Xeon Phi
™
Coprocessor (MIC) Status Sensors Next Steps
Refer to the latest Intel
®
Xeon Phi
™
Coprocessor Adapter specification for the next steps.
