Cooling Subsystem
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
56 Intel order number G90620-002 Revision 1.1
Table 44: Discrete Thermal Sensors Typical Characteristics
Byte
Field
Description
11
Sensor Type
01h = Temperature
12
Sensor Number
See Table 45
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = See Table 45
14
Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset as described in Table 45
15
Event Data 2
Not used
16
Event Data 3
Not used
Table 45: Discrete Thermal Sensors – Next Steps
Sensor
Number
Sensor Name
Event
Type
Event Trigger Offset
Description
Next Steps
Hex
Description
0Dh
SSB Thermal Trip
03h
01h
State Asserted
South Side Bridge (SSB) overheated
1. Check for clear and unobstructed
airflow into and out of the chassis.
2. Ensure the SDR is programmed and
correct chassis has been selected.
3. Ensure there are no fan failures.
4. Ensure the air used for cooling the
system is within the thermal
specifications for the system (typically
below 35°C).
90h
P1 VRD Hot
05h
01h
Limit Exceeded
Processor 1 voltage regulator overheated
91h
P2 VRD Hot
Processor 2 voltage regulator overheated
92h
P3 VRD Hot
Processor 3 voltage regulator overheated
93h
P4 VRD Hot
Processor 4 voltage regulator overheated
94h
P1 Mem01 VRD Hot
Processor 1 Memory 0/1 voltage regulator
overheated
95h
P1 Mem23 VRD Hot
Processor 1 Memory 2/3 voltage regulator
overheated
96h
P2 Mem01 VRD Hot
Processor 2 Memory 0/1 voltage regulator
overheated
