System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
Cooling Subsystem
Revision 1.1 Intel order number G90620-002 51
Sensor
Number
Sensor Name
Next Steps
23h
Baseboard Temperature 2
24h
Baseboard Temperature 3
25h
Baseboard Temperature 4
26h
I/O Mod Temp
27h
PCI Riser 1 Temp
28h
IO Riser Temp
2Ch
PCI Riser 2 Temp
2Dh
SAS Mod Temp
2Eh
Exit Air Temp
2Fh
LAN NIC Temp
5.2.2 Thermal Margin Sensors
Margin sensors are also linear sensors but typically report a negative value. This is not an actual temperature, but in fact an offset to
a critical temperature. Values reported are seen as number of degrees below a critical temperature for the particular component.
The BMC supports DIMM aggregate temperature margin IPMI sensors. The temperature readings from the physical temperature
sensors on each DIMM (such as, Temperature Sensor on DIMM, or TSOD) are aggregated into IPMI temperature margin sensors for
groupings of DIMM slots, the partitioning of which is platform/SKU specific and generally corresponding to fan domains.
The BMC supports global aggregate temperature margin IPMI sensors. There may be as many unique global aggregate sensors as
there are fan domains. Each sensor aggregates the readings of multiple other IPMI temperature sensors supported by the BMC FW.
The mapping of child-sensors into each global aggregate sensor is SDR-configurable. The primary usage for these sensors is to
trigger turning off fans when a lower threshold is reached.
Table 38: Thermal Margin Sensors Typical Characteristics
Byte
Field
Description
11
Sensor Type
01h = Temperature
12
Sensor Number
See Table 40
