Power Subsystems
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
40 Intel order number G90620-002 Revision 1.1
Sensor Specific Offset
Description
ED2
ED3
Next Steps
Hex
Description
02h
Predictive
Failure
Check the data in ED2
and ED3 for more details.
10b = OEM code in Event Data 2
 01h – Output voltage warning
 02h – Output power warning
 03h – Output over-current
warning
 04h –Over-temperature warning
 05h – Fan warning
 06h – Input under-voltage
warning
 07h – Input over-current
warning
 08h – Input over-power warning
10b = OEM code in Event Data 3
Will have the contents of the
associated PMBus* Status
register. For example, Data 3 will
have the contents of the
VOLTAGE_STATUS register at
the time an Output Voltage
warning was detected. Refer to
the PMBus* Specification for
details on specific register
contents
Depends on the warning
event.
1. Replace the power
supply.
2. Verify proper airflow
to the system.
3. Verify the power
source.
4. Replace the system
boards.
03h
A/C lost
AC removed
00b = Unspecified Event Data 2
00b = Unspecified Event Data 3
Informational Event.
06h
Configuration
error
Power supply
configuration is not
supported.
Check the data in ED2 for
more details.
10b = OEM code in Event Data 2
 01h – The BMC cannot access
the PMBus* device on the PSU
but its FRU device is
responding.
 02h – The PMBUS*_REVISION
command returns a version
number that is not supported
(only version 1.1 and 1.2 are
supported).
 03h – The PMBus* device does
not successfully respond to the
PMBUS*_REVISION command.
 04h – The PSU is incompatible
with one or more PSUs that are
present in the system.
 05h –The PSU FW is operating
in a degraded mode (likely due
to a failed firmware update).
00b = Unspecified Event Data 3
Indicates that at least one of
the supplies is not correct for
your system configuration.
1. Remove the power
supply and verify
compatibility.
2. If the power supply is
compatible, it may be
faulty. Replace it.
