Server Board S3000AH User’s Guide 3
Expansion
Capabilities
S3000AHLX SKU:
• Two full length 32-bit/33MHz, 3.3V Universal PCI connectors
• One physical x4 PCI Express* connector (operating at x1 lane speed)
• One full length PCI-X* connector (64-bit/133MHz)
• One Intel
®
Adaptive Slot connector (supports one PCIe* x8 or one PCI-X*
64-bit/133MHz add-in card)
S3000AH SKU:
• Two full length 32-bit/33MHz, 3.3V Universal PCI connectors
• One x8 PCI Express* connector
• One physical x4 PCI Express* connector (operating at x1 lane speed)
• One physical x8 PCI Express* connector (operating at x4 lane speed)
S3000AHV SKU:
• Two full length 32-bit/33MHz, 3.3V Universal PCI connectors
• One x8 PCI Express* connector
• One physical x8 PCI Express* connector (operating at x4 lane speed)
Fans Support for up to four system fans and one processor fan
System
Management
Intel
®
System Management Software
Table 2. Server Board Features
Feature Description
