Intel
®
Server Board S3000AH User’s Guide 9
Figure 4. S3000AH Connector and Component Locations
A. Video Memory B. PCI 32/33 Slot 2 C. ATI* ES1000 Video Controller
D. PCIe* x4 (x1 Lane) Slot 3 E. PCIe* x8 (x4 Lane) Slot 5 F. Intel
®
82541PI Lan Controller
G. PCIe* x8 (x8 Lane) Slot 6 H. LAN SPI Flash I. Intel
®
82573E LAN Controller
J. Clock Generator K. Back Panel Connectors L. Rear System Fan
M. 2x4 Power Connector N. Processor Socket O. Processor Fan
P. DIMM Sockets (2B and 2A) Q. DIMM Sockets (1B and 1A) R. System Front DIMM Blower
Header
S. System Front Processor Blower
Header
T. Chassis Intrusion Header U. Intel
®
S3000 MCH
V. Battery W. 2x12 Main Power Connector X. Front System Fan
Y. Floppy Connector Z. PATA IDE Connector AA. SATA Port 3
BB. SMSC* SCH5027 Super I/O CC. SATA Port 2 DD. Intel
®
82801 ICH7R
EE. Front Panel Connector FF. System Maintenance Mode
Jumper
GG. SATA Port 1
HH. Clear CMOS Jumper II. SATA Port 0 JJ. BIOS SPI Flash
KK. External USB Connector LL. SPI/FWH Select Header MM. SMBus Connector
NN. PCI 32/33 Slot 1
