Intel
®
Server Board S3000AH User’s Guide 11
Figure 5. S3000AHV Connector and Component Locations
A. Video Memory B. PCI 32/33 Slot 2 C. ATI* ES1000 Video Controller
D. PCIe* x8 (x4 Lane) Slot 5 E. PCIe* x8 (x8 Lane) Slot 6 F. LAN SPI Flash
G. Intel
®
82573E LAN Controller H. Clock Generator I. Back Panel Connectors
J. Rear System Fan K. 2x4 Power Connector L. Processor Socket
M. Processor Fan N. DIMM Sockets (2B and 2A) O. DIMM Sockets (1B and 1A)
P. System Front DIMM Blower
Header
Q. System Front Processor Blower
Header
R. Chassis Intrusion Header
S. Intel
®
S3000 MCH T. Battery U. 2x12 Main Power Connector
V. Front System Fan W. Floppy Connector X. PATA IDE Connector
Y. SATA Port 3 Z. SMSC* SCH5027 Super I/O AA. SATA Port 2
BB. Intel
®
82801 ICH7R CC. Front Panel Connector DD. System Maintenance Mode
Jumper
EE. SATA Port 1 FF. Clear CMOS Jumper GG. SATA Port 0
HH. BIOS SPI Flash II. External USB Connector JJ. SPI/FWH Select Header
KK. SMBus Connector LL. PCI 32/33 Slot 1
