Server Board S3000AH User’s Guide 7
Figure 3. S3000AHLX Connector and Component Locations
A. Video Memory B. PCI 32/33 Slot 2 C. ATI* ES1000 Video Controller
D. PCIe* x4 (x1 Lane) Slot 3 E. Intel
®
82541PI Lan Controller F. PCI-X* 64/133 Slot 5
G. LAN SPI Flash H. Intel
®
82573E LAN Controller I. Intel
®
Adaptive Slot, Slot 6
J. Clock Generator K. Back Panel Connectors L. Diagnostic POST LEDs
M. Rear System Fan N. 2x4 Power Connector O. Processor Socket
P. Processor Fan Q. DIMM Sockets (2B and 2A) R. DIMM Sockets (1B and 1A)
S. System Front DIMM Blower
Header
T. System Front Processor Blower
Header
U. Chassis Intrusion Header
V. Intel
®
S3000 MCH W. Battery X. 2x12 Main Power Connector
Y. Front System Fan Z. Floppy Connector AA. PATA IDE Connector
BB. SATA Port 3 CC. SMSC* SCH5027 Super I/O DD. SATA Port 2
EE. Intel
®
82801 ICH7R FF. Front Panel Connector GG. System Maintenance Mode
Jumper
HH. SATA Port 1 II. Clear CMOS Jumper JJ. SATA Port 0
KK. BIOS SPI Flash LL. External USB Connector MM. SPI/FWH Select Header
NN. SMBus Connector OO. Intel
®
6702 PXH-V Controller PP. PCI 32/33 Slot 1
