2 Intel
®
Server Board S3000AH User’s Guide
Table 2 summarizes the features of the server board.
Table 2. Server Board Features
Feature Description
Processor Processor and Front Side Bus (FSB) support
Supports Dual-Core Intel
®
Xeon
®
processor 3000 series, Quad-Core Intel
®
Xeon
®
processor 3200 series, Intel
®
Pentium
®
processor Extreme Edition
(S3000AHLX and S3000AH only), Intel
®
Pentium
®
D processors, Intel
®
Pentium
®
4 processors, and Intel
®
Celeron
®
D processors in the Intel
®
LGA775 package
Supports Intel
®
dual-core technology
Supports Hyper-Threading Technology
Supports Intel
®
Extended Memory System 64 Technology (Intel
®
EM64T)
Memory Four DIMM sockets supporting stacked DDR2 533/667 MHz ECC or non-ECC
unbuffered memory (up to 8 GB of total system memory)
Chipset Intel
®
3000 chipset, consisting of:
Intel
®
3000 Memory Controller Hub (MCH)
Intel
®
I/O Controller Hub (ICH7R)
Intel
®
6702 PXH-V PCI-X* Hub (S3000AHLX SKU only)
Peripheral
Interfaces
External connections:
Stacked PS/2* ports for keyboard and mouse
DB9 Serial A port
Two RJ45 NIC connectors for 10/100/1000 Mb connections
Two USB 2.0 ports
Internal connections:
One USB port header, which supports two USB 2.0 ports
One DH10 Serial B header
Four Serial ATA connectors with embedded RAID 0/1/10 support for Intel
®
Embedded Server RAID Technology and RAID 0/1/5/10 for Intel
®
Matrix
Storage Technology
One ATA-100 connector
ATX-compliant 24-pin control panel header
I/O Controll SMSC* SCH5027 controller
Video On-board ATI* ES1000 video controller with 16MB external video memory
Hard drive
ATA-100 support: one IDE channel capable of supporting up to two drives
SATA (3.0 Gb/s) support
LAN
Intel
®
10/100/1000 82573E Gigabit Ethernet Controller
Intel
®
10/100/1000 82541PI Gigabit Ethernet Controller (S3000AHLX/
S3000AH only)
