Server Board S3000AH User’s Guide 51
• Make sure the drive is compatible. See “Additional Information and Software” for a
link to the tested drives.
• Make sure you have not exceeded the power budget for the server. See “Additional
Information and Software” for a link to software to check your power budget.
• If using SCSI drives, verify that each SCSI ID number is unique on the SCSI bus.
See your drive documentation for details on setting the SCSI ID for your drives.
• If using ATA drives, verify that the master/slave settings are set correctly. See your
drive documentation for details on setting the master/slave settings.
• If using a RAID configuration with SCSI or SATA drives, make sure the RAID card
is installed correctly.
Bootable CD-ROM Disk Is Not Detected
Check the following:
• Make sure the BIOS is configured to allow the CD-ROM to be the first bootable
device.
LED Information
The Intel
®
Server Board S3000AH includes LEDs that can aid in troubleshooting your
system. A table of these LEDs with a description of their use is listed below.
Table 7. LED Information
LED Name Function Location LED Color Notes
Power Indicates system power
is on or off
Front control
panel
Green Off = Power is off or in sleep
state S5
On = Power is on or in sleep
stats S0
ID Aid in server
identification from the
back panel
Front control
panel and
board rear left
corner
Blue Press ID LED button or use
Server Management software
to turn the LED on and off.
System Fault Visible fault warning Control panel
and board rear
left corner
Green or
Amber
Green = No Fault
Green blinking = degraded
condition
Amber blinking = non-critical
error
Amber = critical or non-
recoverable error
