Intel® Server RAID Controller U3-1 User’s Manual Rev 1.0 1-5
Quick Start Instructions
Figure 1-2. SRCU31 Adapter Card
1.3.1 Intel Server RAID Controller U3-1 Hardware Setup
1.3.1.1 Hardware Requirements
• Server with CD-ROM Drive not attached to Intel Server RAID Controller U3-1
A7469-01
Internal 68-pin Connector
External VHDCI Connector
SDRAM DIMM socket
32 MB to 128 MB
Unbuffered, PC 100, ECC
Intel® i960® RN I/O Processor
100 MHz Core
Hardware XOR
16Mb Flash
Flash Recovery
(FRU) Jumper
PCI 64-bit, 33MHz
SDRAM DIMM
Ultra160 SCSI
LSI Logic SYM53C1010
