2-6 Intel® Server RAID Controller U3-1 User’s Manual Rev 1.0
Advanced Installation Steps
Figure 2-2. Three or More SCSI Disk RAID Configuration Selection
2.3.3.2 RAID Configuration Utility - All Disks Already in a RAID Volume
If you select the Create RAID Vol um e option when one or more RAID volumes already exist,then
the “A RAID Volume already exists” screen appears. See Figure 2-3. While in RAID Configuration
Utility you will be unable to create new RAID volumes without first deleting all existing RAID
volume(s).
Note: The number of volumes you can create using RAID Configuration Utility is limited to one.
However, you may select the size of this volume.
Figure 2-3. RAID Volume Already Exists
2.3.3.3 Create a RAID 0 Volume
A RAID 0 volume creation screen is shown in Figure 2-4.
Intel(R) Integrated RAID - RAID Configuration Utility Version 4.05
Copyright(c) Intel Corporation 1998-2000 All Rights Reserved
RAID VOLUME LEVEL:
Please select from the following RAID Volume Creation options.
RAID 0
RAID 1
RAID 5
<- Typical
Arrow Keys to Highlight, ENTER to Select.
Esc for previous menu
Intel(R) Integrated RAID - RAID Configuration Utility Version 4.05
Copyright(c) Intel Corporation 1998-2000 All Rights Reserved
A RAID Volume already exists.
Please use the Advanced RAID Configuration Utility
to create additional RAID Volumes.
Arrow Keys to Highlight, ENTER to Select.
Esc for previous menu
