2-4 Intel® Server RAID Controller U3-1 User’s Manual Rev 1.0
Advanced Installation Steps
2.3 Configuring and Administering RAID Volumes in the
RAID Configuration Utility
2.3.1 Keyboard Navigation
See Table 2-2 for RAID Configuration Utility keyboard functionality.
2.3.2 RAID Configuration Utility – Main Menu
Note: The RAID Configuration Utility is run from BIOS.
If you choose to run the RAID Configuration Utility (Ctrl C at boot-up), the Main Menu appears
(see Figure 2-1, “RAID Configuration Utility - Main Menu” on page 2-5).
The Status Line will vary in the opening screen in Figure 2-1 depending upon the number of disk
drives found, number of RAID volumes configured, number of failed disk drives and the number
of global hot spares declared. The status line in the Figure 2-1 example displays a status of 5 disks
found and no RAID volumes configured.
Table 2-2. RAID Configuration Utility Keyboard Navigation
Key Function
ESC Key Return to Previous Screen
Arrow Keys Navigate between options and/or input fields
Enter Submit Selection
Hot Keys Hot Keys are highlighted in dark blue
