2-16 Intel® Server RAID Controller U3-1 User’s Manual Rev 1.0
Advanced Installation Steps
5. Select Submit, press Enter to confirm the selection. You may cancel your action at any time by
selecting Cancel and pressing Enter, or hitting Esc.
2.3.5 Display Volume Information in RAID Configuration Utility
Click the Display Volume Information button in the RAID Configuration Utility main menu to
view information about existing RAID Volumes. See Figure 2-1. This option displays limited
information. More detailed information may be obtained from Intel Integrated RAID Storage
Console. Figure 2-14 shows the Display Volume Information screen.
Figure 2-14. Display Volume Information
2.3.6 Delete a RAID Volume in RAID Configuration Utility
Use the Delete RAID Volume screen to delete a RAID volume. See Figure 2-15.
Each attached RAID volume is listed in the Display Volume Information screen (Figure 2-15). In
Figure 2-15 the first volume is selected. If no RAID volumes are listed, then the only selectable
option is Reset Entire Configuration.InFigure 2-15 Vo l u me 1 has been selected to be deleted. Press
Enter to delete the highlighted volume. Two confirmation screens appear to verify that you wish to
delete the volume.
Intel(R) Integrated RAID - RAID Configuration Utility Version 4.05
Copyright(c) Intel Corporation 1998-2000 All Rights Reserved
Name Size (MB) Level # of Disks Status
---------- --------- ----- ---------- ----------
Volume1 12873 5 5 Normal
Display Volume Information
Esc for previous menu
Number of Hot Spares: 1
