A-2 Intel® Server RAID Controller U3-1 User’s Manual Rev 1.0
Hardware Details
• Hot Swap Disk Drive support (if disk drive enclosure supports this feature)
• Maximum of 15 Drives supported
• Instant availability/background initialization of RAID Volumes
• Global Hot Spares
• Event Notification
Figure A-2. Intel® Server RAID Controller U3-1 Adapter Card
A7469-01
Internal 68-pin Connector
External VHDCI Connector
SDRAM DIMM socket
32 MB ECC
Expands up to 128 MB
ECC PC66 or PC100 memory
Intel® i960® RN I/O Processor
100 MHz Core
Hardware XOR
16Mb Flash
Flash Recovery
(FRU) Jumper
PCI 64-bit, 33MHz
SDRAM DIMM
Ultra160 SCSI
LSI Logic SYM53C1010
