Intellian Satellite TV Antenna Systems
Command Buttons
•EditSatelliteInformation–Tomodifythesatelliteinformation.
•RegisterforSatA–ToregisterasatellitetosatelliteA.
•RegisterforSatB–ToregisterasatellitetosatelliteB.
•RegisterforSatC–ToregisterasatellitetosatelliteC.(Tri-SatMode)
•NotUse–DonotuseDiSEqC.
•ChangeBand–TouseDiSEqCtochangeband.
•ChangeSatellite–TouseDiSEqCtochangethesatellite.
•SingleBand–AntennainuseofsinglebandLNB.
•UniversalBand–AntennainuseofuniversalLNB.
•SetLocalFrequency–ToselectlocalfrequencyofLNB.

Intellian i6P Specifications

Operating Environment

operating temperature range	-25°C to +55°C
storage temperature range	-40°C to +80°C
humidity limit	95% R.H

Antenna System Performance

frequency	Ku-band (10.7 to 12.75 GHz)
minimum EIRP	46 dBW
azimuth range	680°
elevation range	-5° to +90°
roll	±25°
pitch	±15°
roll and pitch response rate	45° per second
turn rate	45° per second

Power

power requirements	9~30 V DC
power consumption typical	30W
power consumption maximum	50W

Weight and Dimensions

satellite antenna unit dimensions	70 cm x 72 cm
antenna dish diameter	60 cm
antenna control unit dimensions	17.8 cm x 21.7 cm x 5.4 cm
satellite antenna unit weight	21 kg
antenna control unit weight	1.2 kg
