INSTALLING THE ANTENNA

Step 3.

Using a 19mm wrench, remove 4 shipping bolts that mount the antenna to the pallet.

WARNING: When lifting the antenna by using the lifting strap, ensure to disassemble

the antenna and the pallet.
